| Model | 86H-25 | 86H-40 | 86H-55 | 86H-75 | 86H-100 | |
| Rated Capacity | Litres | 25 | 40 | 55 | 75 | 100 |
| Rated Power | kW | 3,000W 230Va.c. 50Hz | ||||
| Approx. Heat Up Time to 60°C | 20 | 32 | 44 | 60 | 80 | |
| Length (A) | mm | 460 | 664 | 868 | 1140 | 973 |
| Diameter (B) | 377 | 461 | ||||
| Inlet & Outlet Spacing (C) | 150 | 240 | ||||
| Mount Hole Spacing (D) | 320 | 340 | 478 | 812 | 632 | |
| Overall Width Heater Unit (E) | 418 | 502 | ||||
| Total Distance from Wall (F) | 426 | 510 | ||||
| Total Height from Ceiling (G) | 396 | 480 | ||||
| Temperature Setting | (°C) | Factory Set 60°C (Maximum 70°C) | ||||
| Temperature & Pressure Relief Valve | kPa | 1,000 | ||||
| Pipe Connection Sizes | Rp 20 (3/4'' x 14) | |||||
| Shipping Weight | kg | 15 | 23 | 28 | 34 | 38 |
